Aluminium Band Saw Blade Butt Welding Machine

Name: Aluminium Band Saw Blade Butt Welding Machine
Brand: Xingweihan
Price: 8 USD

China Aluminium Band Saw Blade Butt Welding Machine wholesale

Brand Name : Xingweihan

Place of Origin : Sichuan, China

Certification : CE, RoHS, ISO

MOQ : 1 set

Price : $8,000-8,500 / set

Frequency : 50 Hz, 60 Hz

input voltage : 380 V, 220V

power (kw) : 4.75 kW, 3.65 kW

Weld method : Butt Welding

condition : New

dimensions : 1350*700*1750mm(53.15*27.56*68.90in)

usage : Meat Saw Blade Welding Machine

warranty : 1 Year

weight (kg) : 600

Product Name : Bandsaw Butt Welding Machine

Application : Bandsaw Blade Flash Butt Welding Machine

Function : Band Saw Butt Welding Machine For 50Mm

Welding Materials : Aluminum Galvanized Stainless Steel Cooper

Usage : Butt Welder Small Blade Butt Welding China

Keywords : Band Saw Blades Welding

Type : Butt Resistance Welding Machine

After Warranty Service : Video technical support, Online support and Spare parts

After-sales Service Provided : Free spare parts, Field installation, commissioning and training

Contact Now

Aluminium Band Saw Blade Butt Welding Machine

Item/Model	DN-40	DN-63	D(T)N-80	D(T)N-100	D(T)N-125	D(T)N-160	D(T)N-200
Rated power At 50%(KVA)	40	63	80	100	125	160	200
Rated primary power(V)	380	380	380	380	380	380	380
Secondary Voltage(V)	5.2	6.7	7.9	8.3	8.6	9.1	10.6
Rated frequency(HZ)	50/60	50/60	50/60	50/60	50/60	50/60	50/60
Max.Short Circuit Current(KA)	14	15	16	18	20	28	34
Max. weld power(KVA)	62	86	170	280	300	330	410
Throat(MM)	400	400	400	450	450	450	450
Max.Froce at electrodes(N)	6000	6000	10000	10000	10000	12000	12000
Working stroke(MM)	20	20	30	40	40	50	50
Cooling Water Consumpion 2.5bar(L/min)	6	6	8	8	8	10	10
Electrodes tip(MM)	Φ13*45	Φ13*45	Φ16*45	Φ16*45	Φ16*45	Φ20*45	Φ20*45
Arms(MM)	Φ50*150	Φ50*150	Φ80*220	Φ80*220	Φ80*220	Φ80*220	Φ80*220
Projection Clamping Plate(MM)	125*125	125*125	200*200	200*200	200*200	200*200	200*200
Max.Welding Capaciry A3 steel(MM)	2.5+2.5	3+3	4+4	4.5+4.5	5+5	5+5	6+6

Product Overview

Aluminium Band Saw Blade Butt Welding Machine

The product employs advanced flash butt welding technology, achieving high-quality welding of saw blades through the coordinated operation of core components such as the mainframe, pneumatic transmission mechanism, secondary circuit, welding transformer, and welding controller. The user-friendly human-machine interface design facilitates rapid operator mastery of the equipment. The transparent protective cover effectively prevents spark splatter during the welding process, enhancing on-site operational safety. The equipment supports butt welding of saw blades with varying cross-sectional areas, accommodating multiple saw blade specifications to meet welding requirements across diverse industries.

1. The host frame has excellent rigidity and long-term operation without deformation: The host frame is made of high-quality steel plate welding or integral casting structure, which has undergone strict aging treatment and stress relief technology, and has extremely high static rigidity and dynamic impact resistance. It can still maintain structural stability under high-frequency welding impact, ensuring long-lasting and reliable welding accuracy.

2. The pneumatic transmission mechanism is durable and reliable, suitable for high-intensity operations: well-known brands of cylinders, solenoid valves, and pneumatic accessories are selected, and key moving parts are treated with wear-resistant materials. The action life can reach over one million times, which can adapt to continuous and high-intensity production rhythms and reduce equipment downtime caused by aging pneumatic components.

3. Wear resistant design of welding electrodes and clamping components, extending replacement cycle: The electrodes are made of high conductivity and high wear resistant copper alloy materials, and the key contact surfaces of the clamping mechanism are hardened to have excellent wear and arc erosion resistance, maintaining good contact under frequent welding conditions and significantly extending the electrode replacement cycle.

4. Standardized layout of the water and gas circuit system, convenient for heat dissipation and maintenance: The internal water and gas circuit system of the equipment adopts a partitioned layout, and the cooling water circuit effectively cools down the heating components such as transformers, electrodes, and secondary circuits. The pipeline identification of the gas circuit system is clear and the connection is reliable, which facilitates daily inspection and regular maintenance, reducing maintenance difficulty.

5. Compact overall structure and high space utilization: The equipment undergoes structural optimization while ensuring complete functionality, occupying a small area for flexible layout in limited workshop space. At the same time, the center of gravity of the entire machine is low and the installation is stable, eliminating the need for complex foundation construction and reducing equipment entry and relocation costs.

Detail Images

Double-layer Cylinder

Provides graded clamping and forging force. Through a double-layer piston structure, a "light first, heavy later" pressure output is achieved - light pressure is used for rapid feed and positioning, while heavy pressure is used for strong forging at the welding terminal to ensure a dense weld seam and avoid impact damage to thin saw blades.

Human Computer Interaction Interface

Implement information exchange between devices and operators. Used for setting and modifying welding parameters, storing and calling multi specification saw blade formulas, real-time monitoring of equipment operation status, and displaying and prompting fault alarm information, making the operation more intuitive and convenient.

Copper Alloy Electrode

Made of high-quality chromium zirconium copper, it offers excellent conductivity and wear resistance. The internal cooling channel ensures efficient heat dissipation, delivering stable and reliable performance for both fixed and moving electrodes.

Waterway Components

All waterway components undergo surface treatment to prevent rusting, and waterway drainage is independently discharged to the water tank. Based on the outflow situation, blockages in the waterway can be observed and eliminated.

General Strctures

Scene images

Our factory can customize according to your requirments. More details, please contact!

Welding Test

Welding Workpiece

Slaughter Saw Blade Size: 16mm x 4 teeth/inch x 0.5mm thick

Metal Cutting Saw Blade Size: 27mm x 5/8 teeth/inch x 0.9mm thick

Woodworking Saw Blade Size: 35mm x 22mm x 1.1mm thick

Saw Blade Width: 6-80mm, saw blade thickness: 0.45-1.6mm
